Full Automatic hard candy making machine

Model No.: TY400 Introduction: Die forming hard candy line is composed of dissolving tank, storage tank, vacuum cooker, cooling table or continuous cooling belt, batch roller, rope sizer, forming machine, transporting belt, cooling tunnel etc. The forming dies for hard candies are in a clamping style which is an ideal device for producing different shapes of hard candies and soft candies, small wastage and high production efficiency. The whole line is manufactured as per GMP standard in accordance with the requirement of GMP Food Industry.

Model	TY400
Capacity	300~400kg/h
Candy Weight	Shell: 8g(Max); Central filling: 2g(Max)
Rated Output Speed	2000pcs/min
Total Power	380V/27KW
Steam Requirement	Steam Pressure:0.5-0.8MPa; Consumption:200kg/h
Working Condition	Room Temperature：20~25℃; Humidity：＜55%
Total Length	21m
Gross Weight	8000kg

Die forming candy line： For production of die formed hard candy, jam center filled hard candy, powder filled hard candy Production flowchart → Raw material dissolving→Storage→Vacuum cooking→Add color and flavor→Cooling→Rope forming→Forming→Final product

Step 2 Boiled syrup mass pump into batch vacuum cooker or micro film cooker through vacuum, heat and concentrated to 145 degrees Celsius. Step 3 Add flavor,color into syrup mass and it flow into cooling belt.

Step 4 After cooling, syrup mass is transferred into batch roller and rope sizer, meanwhile can add jam or powder inside. After rope getting smaller and smaller, it enter forming mould, candy formed and transferred for cooling.

Die forming hard candy line Advantages： 1.Continuously vacuum cooker, guarantee the quality of sugar mass;Suitable for producing jam or powder center-filled hard candies; 2.Different candy shape can be made by changing the moulds; 3.Automatic running steel cooling belt is optional for better cooling effect specification of hard candy line：
